6.1.1 Control word and status word
In the control word (P967) the control requests a drive-internal state transition from
the encoTRive. In the status word (P968) the encoTRive provides information on its
actual status.
Control and status word are always process data and are consequently a fixed
constituent of the cyclic telegram; they must always be placed first in the telegram.
Bit
Value
Significance
Description
0
1
ON
Ready for operation. Voltage on converter.
0
OFF 1
Stop (return to “Ready to switch on” state); decelerate on acceleration ramp
1
1
Operating condition
All “OFF 2” commands are canceled.
0
OFF 2
Disconnection of voltage
2
1
Operating condition
All “OFF 3” commands are canceled.
0
OFF 3
Fast stop; if necessary: remove operating inhibit; stop as fast as possible
3
1
Run enable
Enable electronics and pulses
0
Run inhibit
Drive coasts to a stop and goes to “Ready” state.
4
Specific to operating mode
5
Specific to operating mode
6
Specific to operating mode
7
1
Acknowledge
Fault acknowledged with positive edge (0->1). This is followed by a state
transition to “Switch on inhibit” when the fault has been successfully
removed.
0
without significance
8
1
Jog 1 on
Prerequisite: Run enabled, no positioning operation active.
0
Jog 1 off
9
1
Jog 2 on
Prerequisite: Run enabled, no positioning operation active.
0
Jog 2 off
10
1
Command by control
system
Command undertaken by control system; Process data valid
0
No command
Process data invalid
11
Specific to operating mode
12-15
not used
Table 7: Control word P967 (STW)
