USTER® HVI 900 Instruction Manual
Uster Technologies, Inc. Chapter 7
Version 4.0 (1.99) Module Testing - Page 7-6
3.4.8 Graph Mode
The Graph Mode option is used to indicate if and what type of graph
should be printed to display the test results. The following options can
be selected:
• Fibrogram — The average fibrogram will be printed. The test
data is printed on one page and the fibrogram on the next page.
•
Stress/Strain — The average stress/strain curve will be printed.
The test data is printed on one page and the stress/strain curve on
the next page.
•
Fibrogram/Stress/Strain — Both the fibrogram and the
stress/strain curves are printed. The test data is printed on a
separate page.
• None — No graphs will be displayed.
To print a graph when it is displayed on the screen. Press "P."
3.4.9 External Computer
This selection determines whether or not the test results will be sent to an
external computer system via a serial cable. It alternates between OFF
and ON using the ENTER key.
•
OFF — The test results will not be transmitted to an external
computer system.
• ON — The test results will be transmitted to an external computer.
When the ENTER key is pressed while the
External Computer item is
highlighted, the T
RANSMISSION TYPE MENU will appear (thus selecting the
ON option). It is used to indicate which data should be transmitted.
Each of the options is described below.
