The following information was used to create the Pima Chart. It can be
used as a guideline for designing the Pima chart or other Slant Line-type
charts.
• Name of Color Chart: Type PIMA, press ENTER.
• Number of Chart Lines (1-15): Type 5, press ENTER.
• Line 1, First +b column: Type 4, press ENTER.
• Line 1, First Rd column: Type 80.7, press ENTER.
• Line 1, Second +b column: Type 18, press ENTER.
• Line 1, Second Rd column: Type 60.7, press ENTER.
• Line 1, Label: Type 1, press ENTER.
• Line 2, First +b column: Type 4, press ENTER.
• Line 2, First Rd column: Type 78.2, press ENTER.
• Line 2, Label: Type 2, press ENTER (cursor does
not stop in 2nd +b or Rd columns).
• Line 3, First +b column: Type 4, press ENTER.
• Line 3, First Rd column: Type 75.5, press ENTER.
• Line 3, Label: Type 3, press ENTER (cursor does
not stop in 2nd +b or Rd columns).
• Line 4, First +b column: Type 4, press ENTER.
• Line 4, First Rd column: Type 72.9, press ENTER.
• Line 4, Label: Type 4, press ENTER (cursor does
not stop in 2nd +b or Rd columns).
• Line 5, First +b column: Type 4, press ENTER.
• Line 5, First Rd column: Type 69.4, press ENTER.
• Line 5, Label: Type 5, press ENTER (cursor does
not stop in 2nd +b or Rd columns).
• Label for area below last line: Type 6, press ENTER.
