Firewall Policy Examples
Firebox Vclass User Guide 217
3 Create two separate address groups to represent the
computers in each branch office, using the following
entries in the New Address Group dialog box:
Address Group 1:
Name: Branch_1, Member type: IP Network,
Addresses: 128.100.1.0, Subnet mask: 255.255.255.0
Address Group 2:
Name: Branch_2, Member type: IP Network,
Addresses: 176.14.1.0, Subnet mask: 255.255.255.0
4 Create the following policy on Appliance 1:
5 Create the following policy on Appliance 2:
6 If you want to allow the users in the private network of
branch 2 office to access the computers in the private
network of branch 1 office, create two more policies on
that appliance to permit such traffic. The final list of
policies used by the appliances should look like this:
Policies on Appliance 1
Policies on Appliance 2
Name Src Dest Service In Firewall
Branch_1to2 Branch_1 Branch_2 ANY 0 Pass
Name Src Dest Service In Firewall
Branch_1to2 Branch_1 Branch_2 ANY 1 Pass
Name Src Dest Service Incoming Firewall
Branch_1to2 Branch_1 Branch_2 ANY 0 Pass
Branch_2to1 Branch_2 Branch_1 ANY 1 Pass
Name Src Dest Service Incoming Firewall
Branch_1to2 Branch_1 Branch_2 ANY 1 Pass
Branch_2to1 Branch_2 Branch_1 ANY 0 Pass
