Interface 1 (Public) Information
Firebox Vclass User Guide 397
3 Click Disconnect to break the selected user connection,
including any established tunnels. If an internal IP
address was assigned to this user, it will be returned to
the system for future use.
4 To delete a specific tunnel associated with a RAS user
and force the creation of a new tunnel, select the entry
from the tunnel list and click Delete.
5 To update the tunnel list with the most recent
information, click Refresh.
6 To view a detailed report of a specific tunnel, select an
entry from the tunnel list and then click Details. Most
of the time, a RAS User connection will have only a
single tunnel.
The Detail Tunnel Information dialog box appears.
-Click Refresh to update the Current SAs list with
the most recent information. When you are
finished, click Close to return to the System
Information, Tunnels tab.
- When you are finished, click Close to return to
the RAS User Information window.
Interface 1 (Public) Information
This tab displays the status of interface 1 (Public) and the
IP addressing mode in use–Static, DHCP, or PPPoE. This
tab is not available in Transparent Mode.
1 From the main Vcontroller window, click System
Information.
The System Information dialog box appears.
2 Click the Interface 1 (Public) tab.
The Interface 1 (Public) information is displayed.
