Xerox Phaser 6125 Service Manual

Phaser 6130 Color Laser Printer Service Manual I – 5
Index
out of memory error, 3-22
part number
, 9-25
specifications
, 1-12
supported types
, 1-8, 1-12
menu map
Phaser 6130, A-2
Service Mode
, 4-6
Motor
main motor error, 3-67
sub motor error
, 3-69
troubleshooting Sub Motor
, 4-28
motor
errors, 3-66
troubleshooting Main Motor
, 4-27
MPC Card
, 2-33
MPC card
, 1-8
MPC error
, 3-50
MPC part number
, 9-25
multiple sheet feed prevention
, 2-16
Multi-Protocol Network Card
, 2-33
part number
, 9-25
N
network
error
, 3-24
Ethernet Port
, 1-5
Macintosh troubleshooting
, 4-53
UNIX troubleshooting
, 4-54
Windows troubleshooting
, 4-52
Network Card
description
, 1-8
MPC error
, 3-50
No Paper Sensor, Tray
troubleshooting
, 4-26
NVRAM
error, 3-24
initializing
, 6-6
location
, 2-32
troubleshooting
, 3-75
O
operating environment, 1-13
operating systems
specifications, 1-11
troubleshooting
, 4-52
output tray
, 1-2
Output Tray Extension removal
, 8-15
over-current protection
, 10-18
over-voltage protection
, 10-18
P
PAGEC time error, 3-25
paper
envelopes, 1-19
supported sizes, 1-19
supported types and weights
, 1-19
paper detection
, 2-22
paper path
components
, 2-14
flow diagram
, 2-13
paper setting errors
, 3-56
paper size detection
, 2-34
Paper Tray
components, 2-15
Feed Roller
operation, 2-18
Feed Solenoid
operation
, 2-17
operation
, 2-16
parameter
setting
, 6-7
Plug/Jack
designators list, 10-2
locator diagrams
, 10-6
Power Cord
connector location, 1-5
Power On Self Test (POST)
chain link, 4-3
description
, 4-3
error display
, 4-3
process
, 4-3
type of tests
, 4-3
power requirements
, 1-12
power saver mode
, 1-12
Power Switch
location
, 1-5
operation
, 2-30
print meter
initializing
, 6-6
print volume
, 1-11
printer
configurations
, 1-3
data flow
, 2-33
dimensions
, 1-17
job control functions
, 1-20
operating modes
, 1-14
options
, 1-8
print process
, 2-3
print process diagram
, 2-2
print speed
, 1-13
printing life
, 1-11
resolution
, 1-11
serial number
, 9-2
specifications
, 1-11
technology
, 1-11
printer options
memory
, 1-8
MPC card
, 1-8
print-quality
defect definitions
, 5-20
mode
, 1-11
repeating defect
, 5-21
specifications
, 5-15
guaranteed and maximum print areas
, 5-19
linearity
, 5-17
magnification error
, 5-18

Xerox Phaser 6125 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	17 s
Time to first page (color, normal)	14 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Internal memory	64 MB
Sound power level (standby)	25.7 dB
Sound pressure level (printing)	51.6 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Media weight (tray 1)	64 - 220 gsm
Paper tray media types	Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Letter
Multi-Purpose Tray media weight	64 - 164 g/m²
Power requirements	240 V, 50/60 Hz
Networking features	10/100BaseTX
Power consumption (active)	280 W
Maximum duty cycle	40000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	50 W
Power consumption (PowerSave)	5 W
Storage temperature (T-T)	0 - 35 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	15 - 85 %
Certification	CE, UL 60950-1/CSA 60950-1-03, EMC 89/336/EEC, FCC 15 B, 73/23/EEC, 2002/95/EC

Weight and Dimensions

Dimensions (WxDxH)	400 x 394 x 389 mm
