Xerox Phaser 6125 Service Manual

I – 6 Phaser 6130 Color Laser Printer Service Manual
Index
parallelism, 5-17
perpendicularity
, 5-18
registration
, 5-19
skew
, 5-16
troubleshooting
, 5-20
troubleshooting checklist
, 5-5
process control parameters
, 2-35
admix mode
, 2-36
high area coverage mode
, 2-36
potential
, 2-35
toner density
, 2-35
proof print
, 1-21
R
RAM error, 3-24, 3-26
range check error
, 3-21
Rear Cover removal
, 8-18
registration
components
, 2-22
operation
, 2-21, 2-22
Registration Clutch
operation
, 2-20
troubleshooting
, 4-33
Registration Sensor
Manual Feed operation
, 2-19
troubleshooting
, 4-21
repeating defects
measurements
, 5-21
Pitch Chart
, 5-14, 5-21
replace fuser/fuser life error
, 3-63
report
error history, 1-27
job history
, 1-26
PCL fonts list
, 1-25
PCL macro list
, 1-25
postscript fonts list
, 1-26
print meter
, 1-27
resolution
, 1-11
resources
, 4-55
Right Imaging Unit Restraint Block
removal, 8-38
Right Side Cover removal
, 8-16
S
safety symbols, 1-iv
Scanner, laser
, 2-25
screw types
, 8-6
secure print
, 1-21
Sensor
ADC
, 2-23
color mode switching
, 2-29
error, humidity
, 3-82
Exit
, 2-24
Humidity
, 2-32
Manual Feed No Paper
, 2-19
Registration
, 2-19
Start of Scan (SOS)
, 2-25
Temperature
, 2-32
Tray No Paper
, 2-17
Separator Roller
operation, 2-16
operation and location
, 2-15
removal
, 8-7
serial number
format
, 9-2
location
, 9-2
Service Diagnostics
menu map
, 4-6
Service Kits
Hardware Kit
contents
, 9-26
part number
, 9-26
Packaging Kit part number
, 9-26
Service Mode
accessing
button functions
, 4-5
control panel display
, 4-9
diagnostic tests
, 4-9
menu map
, 4-6
servicing instructions
, 3-4
Side Guide, Paper Tray
operation and location, 2-15
Side Switch - see Toner Access Door Switch
skew measurement, 5-16
specifications
, 1-11
electrical
, 1-12
environmental
, 1-13
functional
, 1-11
, 1-16
media and tray
, 1-19
memory
, 1-12
mounting surface
, 1-18
print-quality
, 5-15
regulatory - Canada
, 1-ix
regulatory - United States
, 1-ix
Start of Scan (SOS)
, 2-25
startup sequence
, 4-2
Sub Motor error
, 3-69
Sub-Drive removal
, 8-53
T
technical support, 1-2
Temperature Sensor
location, 2-30
operation
, 2-32
test print
Black 20% ESS, 5-11
CMY 20% ESS
, 5-12
Contamination Check
, 5-14
Cyan 20% ESS
, 5-10
Gradation ESS
, 5-12
Grid 2 ESS
, 5-9
Magenta 20% ESS
, 5-10
no image IOT
, 5-8
Pattern IOT
, 5-9
Toner Pallet Check
, 5-13
Yellow 20% ESS
, 5-11

Xerox Phaser 6125 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	17 s
Time to first page (color, normal)	14 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Internal memory	64 MB
Sound power level (standby)	25.7 dB
Sound pressure level (printing)	51.6 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Media weight (tray 1)	64 - 220 gsm
Paper tray media types	Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Letter
Multi-Purpose Tray media weight	64 - 164 g/m²
Power requirements	240 V, 50/60 Hz
Networking features	10/100BaseTX
Power consumption (active)	280 W
Maximum duty cycle	40000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	50 W
Power consumption (PowerSave)	5 W
Storage temperature (T-T)	0 - 35 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	15 - 85 %
Certification	CE, UL 60950-1/CSA 60950-1-03, EMC 89/336/EEC, FCC 15 B, 73/23/EEC, 2002/95/EC

Weight and Dimensions

Dimensions (WxDxH)	400 x 394 x 389 mm
