Xerox WorkCentre 5020 Service Documentation

July, 2007
6-21
WorkCentre 5020
General Procedures
Initial Issue
33 26 ESS IF Platen Fast Scan REGI
Adjustment
0~144 1dot
(600dpi)
72 O O O 0-71=-72 to -1dot
72=0dot
73-144=1 to 72dot
33 27 ESS IF Platen Slow scan REGI
Adjustment
0~151 1dot
(600dpi)
24 O O O 0-23=-24 to -1dot
24=0dot
25-144=1 to 151dot
33 28 ESS IF ADF Fast Scan REGI
Adjustment
0~144 1dot
(600dpi)
72 O O O 0-71=-72 to -1dot
72=0dot
73-144=1 to 72dot
33 29 ESS IF ADF Slow scan REGI
Adjustment
0~79 0.1mm 40 O O O 0-39=-4.0 to -0.1mm
40=0mm
41-80=0.1 to 4.0mm
33 30 ESS IF Shading Offset for ADF 1~254 1 100 O O O complement
100=x1
1-99=x0.01-x0.99 (dark)
101-254=x1.01-x2.54 (light)
33 31 ESS IF Shading Offset for ADF 1~254 1 100 O O O complement
100=x1
1-99=x0.01-x0.99 (dark)
101-254=x1.01-x2.54 (light)
33 33 ESS IF Platen Slow Scan scale
Adjustment
0~20 0.10% 10 O O O 0-9=-1.0% to -0.1%
10=0%
11-20=0.1% to 1.0%
33 35 ESS IF ADF Slow Scan scale
Adjustment
0~20 0.10% 10 O O O 0-9=-1.0% to -0.1%
10=0%
11-20=0.1% to 1.0%
33 36 ESS IF ADF Loop Adjustment 0~10 1mm 5 O O O 0-4=-5 to -1mm
5=0mm
1-5=1 to 5mm
33 37 ESS IF M/C config 0~1 - 1 O X X 0 : DC
1 : CPS
33 38 ESS IF ADF installation 0~1 - 0 O O X 0 : not installed
1 : installed
Chain
Func
tion Sub Contents of Data Range Unit
Initial
Value
CE
Access
RemarksRWInit
