Xerox WorkCentre 5020 Service Documentation

July, 2007
3-5
WorkCentre 5020
IQ5, IQ6
Image Quality
Initial Issue
IQ5 Residual Image (Ghosting) RAP
Ghost images appear on the paper. Parts of the previous page or current page appear as ghost
images on the paper.
Procedure
Remove the Drum Cartridge (PL 4.1) (REP 4.1.1) and reinstall it properly. Turn the power OFF
then ON and make a print.
The problem recurs.
YN
Completed
Install a new Drum Cartridge (PL 4.1) (REP 4.1.1). Turn the power OFF then ON and make a
print.
The problem recurs.
YN
Completed
Remove the Fuser (PL 5.1) (REP 5.1.1), lower the green levers on both sides, turn the Drive
Gear of the Heat Roll and check the Heat Roll surface for dirt and/or contamination.
The sur-
face of the Heat Roll is clean.
YN
Remove any dirt and/or contamination. If you can’t clean the surface of the Heat Roller,
replace the Fuser (PL 5.1) (REP 5.1.1).
Replace the AIOC PWB (PL 8.1) (REP 8.1.1).
IQ6 Background RAP
The whole page or part of the page is contaminated by toner. The contamination appears as a
very light grayish color.
Procedure
Check for dirt on the Platen Glass. The Platen Glass is clean.
YN
Remove any dirt from the Platen Glass. If you cannot clean the Platen Glass, replace the
IIT Upper Cover (PL 10.2) (REP 10.2.1).
Remove the Drum Cartridge (PL 4.1) (REP 4.1.1) and reinstall it properly. Turn the power OFF
then ON and make a print.
The problem recurs.
YN
Completed
Install a new Drum Cartridge (PL 4.1) (REP 4.1.1) and install it properly. Turn the power OFF
then ON and make a print.
The problem recurs.
YN
Completed
Check the Transfer Corotron (PL 4.3) (REP 4.3.1). The Transfer Corotron (PL 4.3) (REP
4.3.1) is clean and not damaged.
YN
Clean the Transfer Corotron (PL 4.3) (REP 4.3.1). If it is damaged, replace it.
Remove the HVPS (PL 8.2) (REP 8.2.1) and reinstall it properly. Turn the power OFF then ON
and make a print.
The problem recurs.
YN
Completed
Replace the AIOC PWB (PL 8.1) (REP 8.1.1), followed by the HVPS (PL 8.2) (REP 8.2.1).

Xerox WorkCentre 5020 Specifications

General

Print Technology	Laser
Print Speed	Up to 20 ppm
Print Resolution	Up to 600 x 600 dpi
Max Paper Size	A3
Standard Paper Capacity	250 sheets
Bypass Tray Capacity	100 sheets
Duplex Printing	Manual
Copy Speed	Up to 20 cpm
First Page Out Time (Copying)	Less than 10 seconds
Scan Resolution	Up to 600 x 600 dpi
Operating System Compatibility	Windows, Mac OS
Automatic Document Feeder	50 sheets
Connectivity	USB 2.0
Functions	Print, Copy
Reduction / Enlargement	25% - 400%
Scan Destinations	USB, Email
Fax Transmission Speed	33.6 kbps
First Page Out Time (Printing)	Less than 8 seconds
