July, 2007
6-39
WorkCentre 5020
Glossary of Terms
General Procedures
Initial Issue
Consumables
Machine CRU Strategy
Machine LCB is designed to interface with a CRUM and Billing Counter on all configurations.
The CRUM can be used to provide a "hard stop" capability for markets requiring this feature.
The primary uses of the CRUM are to ensure that the CRU being used is correct for the market
& service/warranty agreements, store the number of copies made on the CRU, and enforce the
end-of-life point. The primary uses of the Counter are to indentify the machine's market loca
-
tion, electronically store the machine's serial number, and store the number of copies made on
the machine.
Consumable Replacement Intervals (TBD)
This specification is applied when the machine is operated under the following conditions:
– Paper: A4 LEF
– Paper Tray: Tray 1
– Copy Mode (not Print Mode)
Glossary of Terms
Table 1
ITEM YIELD/LIFE STRATEGY/REPLACEMENT
Toner 6K @ 5% area coverage of A4 size
Test pattern
Warning/Hard Stop
- Warning with approximately 100
copies of toner remaining.
Drum Car-
tridge
Hard Stop: 22K @ 5% A4 area cover-
age for XC
Job Size = 4 pages
End of life Warning/Hard Stop
- Warning at 16K
Hard Stop at 22K (XC)
Table 1
Term Description
A3 Paper size 297 millimeters (11.69 inches) x 420 millimeters (16.54 inches).
A4 Paper size 210 millimeters (8.27 inches) x 297 millimeters (11.69 inches).
AC Alternating Current is type of current available at power source for machine.
ACT Advanced Customer Training: teaches customers to perform some of service that is
normally performed by Xerox Service Representative.
A/D Analog to Digital refers to conversion of signal
ADF Automatic Document Feeder
ADJ Adjustment Procedure
Bit Binary digit, either 1 or 0, representing an electrical state.
CCD Charge Coupled Device (Photoelectric Converter)
CD 1: Circuit Diagram; 2: Compact Disc
CF Copier Fax
CP Copier Printer
CPF Copier Printer Fax
Chip Integrated Circuit (IC)
CRU Customer Replaceable Unit
CVT Constant Velocity Transport
DADF Duplexing Automatic Document Feeder
DC Direct Current is type of power for machine components. Machine converts AC
power from power source to DC power.
DC Digital Copier
DMM Digital Multimeter is generic name for meter that measures voltage, current, or elec-
trical resistance.
Duplex 2-sided printing or copying
EME Electromagnetic Emissions are emitted from machine during normal operation and
power of these emissions are reduced by machine design features.
ERU Engineer Replaceable Unit
ESD Electrostatic Discharge. A transfer of charge between bodies at different electrostatic
potential.
FS Fax Scanner
FS Fast Scan (direction) - Inboard - to - Outboard
ESS Electronic Sub-System
ENG English
2TM Two Tray Module
FAX Facsimile
FIC Final Integration Center
GND Ground
HFSI High Frequency Service Item
HVPS High Voltage Power Supply
