July, 2007
7-35
WorkCentre 5020
Wiring Data
Initial Issue
Wirenets
FS32FS31
F25F28
THERMOSTAT
J600
LOW
VOLTAGE
POWER
SUPPLY
F26
FS11
POWER CORD
BLK
WHT
POWER SWITCH
7.2.1 WIRE NET AC POWER (HOT)
BLK
BRN
GN/YL
FS60
LOW
VOLTAGE
POWER
SUPPLY
J5
1
CHOKE COIL
J5
2
J3
3
FUSER LAMP
BLK
P600
2
BLK
1.1
10.1
(SEE WIRE NET
AC POWER (NEUT))
1
1
Wire Color
BLK: 100V M/C, BRN: 200V M/C
BLK BLK
FUSER
J600 F27
7.2.2 WIRE NET AC POWER (NEUT)
FS34FS33FS12
POWER CORD
WHT
POWER SWITCH
GN/YL
FS60
LOW VOLTAGE
POWER SUPPLY
J3
1
FUSER LAMP
WHT
P600
1
WHT
10.1
(SEE WIRE NET
AC POWER (HOT))
BLK
DC POWER
GENERATION
1
Wire Color
WHT: 100V M/C, BLU: 200V M/C
1
FUSER
BLU
