Xerox WorkCentre 5020 Service Documentation

July, 2007
2-10
WorkCentre 5020
Initial Issue
Status Indicator RAPS
C2-3
Error Name
STM Regi SNR on JAM
Explanation
• When feeding paper from the STM, timeout between Tray1 Feed Sensor ON and IOT Registration Sensor ON.
I/O Diagnostic Codes (How to Enter the Diagnostic Mode)
• [08-05] IOT Registration Sensor
• [08-10] IOT Registration Clutch
Check Items
• Take Away Roll 1 dirty, contaminated with paper dust, worn, or faulty
• IOT Registration Sensor dirty and Sensor Actuator deformed or damaged
• Paper damaged, not within specification, or not loaded correctly
• Foreign matter, burrs, or paper in the paper path
• Drive gear worn or damaged
• IOT Registration Clutch faulty
• Check that the following wires are connected securely with good electrical contact. If there is no problem, replace the Tray 1 Feed Sensor
(PL 2.5) (REP 2.5.1).
– Wire between Tray 1 Feed Sensor J158-3 ( P/J158) and LVPS J501-6 ( P/J502)
– Wire between Tray 1 Feed Sensor J158-2 and LVPS J501-7
– Wire between Tray 1 Feed Sensor J158-1 and LVPS J501-8
• Check that the following wires are connected securely with good electrical contact. If there is no problem, replace the IOT Registration Sen-
sor (PL 2.9).
– Wire between Tray 1 Feed Sensor J156-3 ( P/J156) and LVPS J503-1 ( P/J503)
– Wire between Tray 1 Feed Sensor J156-2 and LVPS J503-2
– Wire between Tray 1 Feed Sensor J156-1 and LVPS J503-3
• Replace the IOT Registration Clutch (PL 2.9) and the AIOC PWB (PL 8.1) (REP 8.1.1) in that order.
O -
CH8.1
Figure 1
CH8.4
Figure 4
C5-0
Error Name
No paper in the selected paper tray (Tray1)
Explanation
• No paper is detected in Tray1 when ATS function is disabled and Tray1 is selected during a copy job.
• No paper is detected in Tray1 when Tray1 is selected during a print job (the paper size setting matches the one specified for the job).
I/O Diagnostic Codes
[07-07] Tray1 No Paper Sensor
Check Items
• Press the [Stop] button on the Control Panel.
• Check the tray to see if it is empty; if it is, add paper specified by the job.
• Tray1 No Paper Sensor dirty and Sensor Actuator deformed or damaged
• Check that the following wires are connected securely with good electrical contact. If there is no problem, replace the Tray 1 No Paper Sen-
sor (PL 2.7) (REP 2.7.1).
– Wire between Tray1 No Paper Sensor J157-3 ( P/J157) and LVPS J501-3 ( P/J501)
– Wire between Tray1 No Paper Sensor J157-2 and LVPS J501-4
– Wire between Tray1 No Paper Sensor J157-1 and LVPS J501-5
• Replace the AIOC PWB (PL 8.1) (REP 8.1.1).
X -
CH7.1
Figure 1
Error
Code Error Name/Explanation/I/O Diagnostic Codes/Check Items
Record in
Error Log RAP BSD
