Xerox WorkCentre 5020 Service Documentation

July, 2007
6-28
WorkCentre 5020
Initial Issue
General Procedures
43 30 ESS IF Last 20 Fault History 20th 1st 48~122 - 48 O O O
43 40 ESS IF Offset to the latest error 0~19 - 0 O O O
50 15 EXIT Enable OCT & Inverter 0~2 - 2 O O O 0:Disable
1:Inverter+OCT
2:Inverter Only
50 20 FUSER FSR Reset FuserOverTemp 0~3 - 0 O O O 0:reset
1:FS1 Detected over temp
2:FS2 Detected over temp
3:On time Fail
5:Cold Sagging Fail(Only reset is possible
in the diagnostics mode.)
60 01 ESS IF MCU VERSION 0~1 - - O X X
60 02 ESS IF MCU Release Number 0~99 - - O X X
60 03 ESS IF MCU Patch Level 0~99 - - O X X
60 06 ESS IF STM Version 0~99 - - O X X
60 07 ESS IF STM Release Number 0~99 - - O X X
60 18 General CPM 0~99 - - O X X 20:20PPM
Other:PPM NG
60 19 General Market Identity 0~254 - - O X X 22: DMO
60 26 MC Code Serial Code1 0~254 1 0 O X X
60 27 MC Code Serial Code2 0~254 1 0 O X X
60 28 MC Code Serial Code3 0~254 1 0 O X X
60 29 MC Code Serial Code4 0~254 1 0 O X X
60 30 MC Code Serial Code5 0~254 1 0 O X X
60 31 MC Code Serial Code6 0~254 1 0 O X X
60 32 MC Code Serial Code7 0~254 1 0 O X X
60 33 MC Code Serial Code8 0~254 1 0 O X X
60 34 MC Code Serial Code9 0~254 1 0 O X X
Chain
Func
tion Sub Contents of Data Range Unit
Initial
Value
CE
Access
RemarksRWInit

Xerox WorkCentre 5020 Specifications

General

Print Technology	Laser
Print Speed	Up to 20 ppm
Print Resolution	Up to 600 x 600 dpi
Max Paper Size	A3
Standard Paper Capacity	250 sheets
Bypass Tray Capacity	100 sheets
Duplex Printing	Manual
Copy Speed	Up to 20 cpm
First Page Out Time (Copying)	Less than 10 seconds
Scan Resolution	Up to 600 x 600 dpi
Operating System Compatibility	Windows, Mac OS
Automatic Document Feeder	50 sheets
Connectivity	USB 2.0
Functions	Print, Copy
Reduction / Enlargement	25% - 400%
Scan Destinations	USB, Email
Fax Transmission Speed	33.6 kbps
First Page Out Time (Printing)	Less than 8 seconds
