Xerox WorkCentre 5020 Service Documentation

July, 2007
7-12
WorkCentre 5020
Initial Issue
Wiring Data
Figure 1 4.1 Main Drive
ABCDEFGHJ
1
2
3
4
5
6
T81T82
AIOC PWB
PL8.1
LVPS
PL8.1
J504
4
1
2
P/J407
B2
INTLK
+24VDC
(1.2)
DC COM
(1.1)
IOT MOTOR
PL1.1
J201
4
1
2
J201
3
MOT
AIOC PWB
PL8.1
LVPS
PL8.1
J504
3
P/J407
B3
+5VDC
4.1 MAIN DRIVE
U0-1
U1-1
IOT MOTOR
ON(H) +5VDC
4-1
IOT MOTOR LOCK(H) +5VDC
Fuser CRU
Regi
Dupulex
Tray
Fail Code
U0-1
U1-1
IOT Motor Stop Error
IOT Motor Rotation Error
BLU BLU
RED RED
BLK BLK
YEL
YEL
INLET FRAME DRV ESD GND
F155T30
IOT ESD GNDDRV ESD GND
GN/YL
GRN
F3

Xerox WorkCentre 5020 Specifications

General

Print Technology	Laser
Print Speed	Up to 20 ppm
Print Resolution	Up to 600 x 600 dpi
Max Paper Size	A3
Standard Paper Capacity	250 sheets
Bypass Tray Capacity	100 sheets
Duplex Printing	Manual
Copy Speed	Up to 20 cpm
First Page Out Time (Copying)	Less than 10 seconds
Scan Resolution	Up to 600 x 600 dpi
Operating System Compatibility	Windows, Mac OS
Automatic Document Feeder	50 sheets
Connectivity	USB 2.0
Functions	Print, Copy
Reduction / Enlargement	25% - 400%
Scan Destinations	USB, Email
Fax Transmission Speed	33.6 kbps
First Page Out Time (Printing)	Less than 8 seconds
