Xerox WorkCentre 5020 Service Documentation

July, 2007
7-14
WorkCentre 5020
Initial Issue
Wiring Data
Figure 1 6.1 Image Input
ABCDEFGHJ
1
2
3
4
5
6
IIT PWB
AIOC PWB
PL8.1
6.1 IMAGE INPUT
J410
22
24
LENS ASSEMBLY
PL10.7
J720
13
11
J720
2,3,4,5
,7,8,9,
10,
12,13,
14,16,
18,20
AIOC PWB
PL8.1
CCD SHFT CLK0
CCD SHFT CLK1
VIDEO DATA
26
28
30
CCD
9
7
5
CCD RST CLK
CCD CLMP CLK
CCD TRNSF CLK
J410
33,32,
31,30,
28,27,
26,25,
23,22,
21,19,
17,15
USER INTERFACE
PWB
PL8.4
J711
1
PLATEN OPEN
SWITCH
PL10.5
MAGNET
DC COM
(2.1)
USER INTERFACE PWB
PL8.4
J711
2
+5VDC
PLATEN OPEN SWITCH
COVER CLOSED(L) +5VDC
5-10
PLATEN OPEN SWITCH
LENS ASSEMBLY
A5-1
A5-1
Fail Code
Platen Cover Open
BLK BLK
