Xerox WorkCentre 5020 Service Documentation

July, 2007
7-18
WorkCentre 5020
Initial Issue
Wiring Data
Figure 1 7.1 Tray 1 Paper Stacking
ABCDEFGHJ
1
2
3
4
5
6
AIOC PWB
PL8.1
7.1 TRAY1 PAPER STACKING
LVPS
PL8.1
J501
3
4
TRAY1 NO PAPER
SENSOR
PL2.7
J157
3
P203
3
J203
1
2 2 2
J157
1
J203
3
P203
1
+5VDC
(1.1)
DC COM
(1.1)
LVPS
PL8.1
J501
5
C5-0
+5VDC
P/J407
A19
TRAY1 NO PAPER SENSOR
PAPER SENSED(L) +5VDC
TRAY1
INTERLOCK
SWITCH
PL2.5
9
DC COM
(1.1)
J161
2
J161
1
10
B22
+5VDC
E6-1
TRAY1 INTERLOCK SWITCH
COVER OPEN(H) +5VDC
7-7
1-11
Fail Code
C5-0
E6-1
No paper in the selected paper tray (Tray1)
TRAY1 INTERLOCK SWITCH
TRAY1 NO PAPER SENSOR
L/H Lower Cover open
BLU
BLU
BLU
BLU
BLU BLU
BLU BLUBLU BLU

Xerox WorkCentre 5020 Specifications

General

Print Technology	Laser
Print Speed	Up to 20 ppm
Print Resolution	Up to 600 x 600 dpi
Max Paper Size	A3
Standard Paper Capacity	250 sheets
Bypass Tray Capacity	100 sheets
Duplex Printing	Manual
Copy Speed	Up to 20 cpm
First Page Out Time (Copying)	Less than 10 seconds
Scan Resolution	Up to 600 x 600 dpi
Operating System Compatibility	Windows, Mac OS
Automatic Document Feeder	50 sheets
Connectivity	USB 2.0
Functions	Print, Copy
Reduction / Enlargement	25% - 400%
Scan Destinations	USB, Email
Fax Transmission Speed	33.6 kbps
First Page Out Time (Printing)	Less than 8 seconds
