Xerox WorkCentre 5020 Service Documentation

July, 2007
7-24
WorkCentre 5020
Initial Issue
Wiring Data
Figure 4 8.4 Paper Registration
ABCDEFGHJ
1
2
3
4
5
6
AIOC PWB
PL8.1
8.4 PAPER REGISTRATION
LVPS
PL8.1
J503
1
2
IOT REGI.
SENSOR
PL2.9
J156
3
2
J156
1
+5VDC
(1.1)
DC COM
(1.1)
LVPS
PL8.1
J503
3
C2-3
+5VDC
P/J407
A4
IOT REGI. SENSOR
PAPER SENSED(L) +5VDC
IOT REGI.
CLUTCH
PL2.9
5
+24VDC
(1.1)
P640
1
IOT REGI. CLUTCH
ON(L) +24VDC
8-5
8-10
BLU BLU
BLU BLU
AIOC PWB
PL8.1
4
J640
2
2 1
DC COM
P/J407
A6
BLU BLU
BLU
BLU
BLU
BLU
IOT REGI. SENSOR
IOT REGI. CLUTCH
C6-2
C9-3
E1-6
Fail Code
STM IOT Regi. Sensor on JAM
C2-3
C9-3
E1-6
Manual Bypass IOT Regi. Sensor on JAM
IOT Regi. Sensor Static JAM
IOT Motor
Regi. Roll
C1-2
Tray1 Regi. Sensor on JAM
C1-2
The H/L level is displayed on the UI display
1
1

Xerox WorkCentre 5020 Specifications

General

Print Technology	Laser
Print Speed	Up to 20 ppm
Print Resolution	Up to 600 x 600 dpi
Max Paper Size	A3
Standard Paper Capacity	250 sheets
Bypass Tray Capacity	100 sheets
Duplex Printing	Manual
Copy Speed	Up to 20 cpm
First Page Out Time (Copying)	Less than 10 seconds
Scan Resolution	Up to 600 x 600 dpi
Operating System Compatibility	Windows, Mac OS
Automatic Document Feeder	50 sheets
Connectivity	USB 2.0
Functions	Print, Copy
Reduction / Enlargement	25% - 400%
Scan Destinations	USB, Email
Fax Transmission Speed	33.6 kbps
First Page Out Time (Printing)	Less than 8 seconds
