Xerox WorkCentre 5020 Service Documentation

July, 2007
7-46
WorkCentre 5020
Initial Issue
Wiring Data
7.1.2 P/J List
Table 1
P/J No.
Figure
No.
Item No. Description
F25 Figure 5 1 Fuser Thermostat
F26 Figure 5 4 Fuser Lamp
F27 Figure 5 3 Fuser Lamp
F28 Figure 5 2 Fuser Thermostat
FS11 Figure 9 4 Inlet
FS12 Figure 9 6 Inlet
FS151 Figure 4 8 LH Cover Interlock Switch
FS152 Figure 4 7 LH Cover Interlock Switch
FS153 Figure 3 4 Front Cover Interlock Switch
FS154 Figure 3 5 Front Cover Interlock Switch
FS31 Figure 9 7 Power Switch
FS32 Figure 9 1 Power Switch
FS33 Figure 9 3 Power Switch
FS34 Figure 9 2 Power Switch
FS60 Figure 9 5 Inlet GND
IIT4 Figure 1 5 Carriage Sensor
IIT5 Figure 1 6 Carriage Motor
INV CN1 Figure 1 2 Inverter PWB
INV CN2 Figure 1 1 Inverter PWB
J411 Figure 7 1 AIOC PWB
J508 Figure 6 8 STM
J610 Figure 8 2 CRU
NBCR CN6 Figure 1 7 NBCR PWB
NSC CN1 Figure 1 8 NSC PWB
P412 Figure 7 14 AIOC PWB
P417 Figure 7 16 AIOC PWB
P418 Figure 7 15 AIOC PWB
P419 Figure 7 2 AIOC PWB
P508 Figure 9 15 LVPS
P610 Figure 8 9 CRU
P/J3 Figure 9 18 Fuser Lamp
P/J5 Figure 9 17 Choke Coil
P/J110 Figure 3 6 Toner Empty Sensor
P/J130 Figure 2 2 ROS MPA
P/J140 Figure 2 5 ROS
P/J153 Figure 4 1 Fuser Exit Sensor
P/J156 Figure 4 4 IOT Regi. Sensor
P/J157 Figure 3 7 Tray 1 No Paper Sensor
P/J158 Figure 4 6 Tray 1 Feed Sensor
P/J160 Figure 2 6 ROS, Video
P/J161 Figure 4 5 Tray 1 Interlock Sensor
P/J171 Figure 6 2 STM No Paper Sensor
P/J172 Figure 6 1 STM Feed Sensor
P/J173 Figure 6 3 STM Interlock Switch
P/J201 Figure 8 6 IOT Motor
P/J201 Figure 2 4 ROS, SOS PWB
P/J2011 Figure 2 1 ROS, SOS PWB
P/J202 Figure 8 7 Tray 1 Feed Clutch
P/J203 Figure 8 8 Tray 1 No Paper Sensor
P/J210 Figure 3 1 Erase Lamp
P/J212 Figure 6 4 STM Feed Clutch
P/J401 Figure 7 6 UI
P/J402 Figure 7 11 CRU ID
P/J403 Figure 7 12 ROS
P/J404 Figure 7 5 ROS, Video
P/J405 Figure 7 9 Nohad Fan
P/J406 Figure 7 8 HVPS
P/J407 Figure 9 16 LVPS-AIOC PWB
P/J408 Figure 7 13 AIOC PWB
P/J409 Figure 7 4 AIOC PWB
P/J410 Figure 7 3 AIOC PWB
P/J414A/B Figure 7 7 AIOC PWB
P/J416 Figure 7 10 AIOC PWB
P/J501 Figure 9 13 LVPS
P/J502 Figure 9 10 LVPS
P/J503 Figure 9 12 LVPS
P/J504 Figure 9 9 LVPS
P/J505 Figure 9 14 LVPS
P/J506 Figure 9 11 LVPS
P/J509 Figure 9 8 LVPS
P/J520 Figure 3 3 HVPS
P/J521 Figure 3 2 HVPS
P/J540 Figure 6 7 STM
P/J541 Figure 6 5 STM Feed Motor
P/J542 Figure 6 6 STM (TOTAL CL, SNR, SW)
P/J600 Figure 4 2 Fuser Lamp
P/J601 Figure 4 3 Fuser Thermistor
P/J620 Figure 2 3 ROS MPA
Table 1
P/J No.
Figure
No. Item No. Description
