Xerox WorkCentre 5225 Service Manual

February, 2008
6-68
WorkCentre 5225, 5230
Launch Version
General Procedures
Chain 780-xxx IOT
Table 7 IOT
Chain-
Link
Content Default Range Meaning
780-013 Tray1 Paper Type 1 1~255 1: STATIONERY, 2: TRANSPARENCY, 3: ENVELOPE, 4: ENVELOPE_PLAIN, 5:
ENVELOPE_WINDOW, 6: LABEL, 7: FORM, 8:COATING1, 9: TRACABLE, 10: THICK1,
11:THICK1_REV, 12: THICK2, 13: THICK2_REV, 14: RECYCLED, 15:
CONTINUOUS_LONG, 16: CONTINUOUS_SHORT, 17: TAB_STOCK, 18: MULTI_LAYER,
19: OPAQUE_FILM, 20: TACK_FILM, 21: THIN, 22: FINE, 23: USER1, 24: USER2, 25:
USER3, 26: USER4, 27: USER5, 28: OTHER, 29: WRAPPINGPAPER, 30: EXLUSTERPA
-
PER, 31: COATING2, 32: COATING1_REV, 33: COATING2_REV, 34: THICK1_FINISHER,
35: COATING1_FINISHER, 36: THICK1_A, 37: THICK1_B, 38: THICK1_C, 39: THICK1_S,
40: THICK2_A, 41: THICK2_B, 42: THICK2_C, 43: THICK2_D, 44: THICK2_S, 45:
THICK1_FINISHER_A, 46: THICK1_FINISHER_B, 47: THICK1_FINISHER_C, 48:
THICK1_FINISHER_S, 49: HAGAKI, 50: HAGAKI_REV, 51: STATIONARY_REV, 52:
FINE_REV, 53: RECYCLED_REV, 54: SPECIAL, 55: SPECIAL_REV 56: USED, 57:
PREPUNCHED, 58: TAB_THICK1, 59: TAB_THICK2.
780-014 Tray2 Paper Type 1: Plain 1~255 Same as above
780-015 Tray3 Paper Type 1: Plain 1~255 Same as above
780-016 Tray4 Paper Type 1: Plain 1~255 Same as above
780-018 SMH Paper Type 1: Plain 1~255 Same as above
780-019 Custom Paper Name 1 NULL ASCII numerals, symbols Max. 24 characters (M/N)
780-020 Custom Paper Name 2 NULL Same as above
780-021 Custom Paper Name 3 NULL Same as above
780-022 Custom Paper Name 4 NULL Same as above
780-023 Custom Paper Name 5 NULL Same as above
780-024 IOT Control SMH Free Size Detect for Print
Job
0 0~1 0: Do not perform, 1: Perform
780-025 Image Quality Control Category: Height 0~60 -
780-026 Image Quality Control Category: Plain
Paper
0~60 -
780-027 Image Quality Control Category: Recycle
Paper
0~60 -
780-028 Image Quality Control Category: User
Defined Paper 1
0~60 -
780-029 Image Quality Control Category: User
Defined Paper 2
0~60 -
780-030 Image Quality Control Category: User
Defined Paper 3
0~60 -
780-031 Image Quality Control Category: User
Defined Paper 4
0~60 -
780-032 Image Quality Control Category: User
Defined Paper 5
0~60 -
780-033 Image Quality Control Category: Heavy-
weight Paper 1
0~60 -
