Xerox WorkCentre 5225 Service Manual

February, 2008
7-19
WorkCentre 5225, 5230
Plug/Jack Locations
Wiring Data
Launch Version
P/J609 Figure 7 8 Duplex Unit, MPT
P/J610 Figure 3 6 HVPS, Dispens Motor, Fuser Exit Sensor
P/J613 Figure 13 2 IOT Rear Location
P/J620 Figure 4 9 ROS Unit, Exit PWB
P/J661A Figure 17 8 Tray3/4 Feeder(2TM)
P/J661A Figure 20 4 TTM Rear Location
P/J661B Figure 17 9 Tray3/4 Feeder(2TM)
P/J661B Figure 19 7 TTM Rear Location
P/J700 Figure 2 11 IIT
P/J702 Figure 2 6 IIT
P/J703 Figure 2 5 IIT
P/J720 Figure 2 9 IIT
P/J721 Figure 2 1 IIT
P/J722 Figure 2 13 IIT
P/J725 Figure 2 2 IIT
P/J727 Figure 2 15 IIT
P/J728 Figure 2 7 IIT
P/J750 Figure 2 3 IIT
P750 Figure 22 15 DADF 2 of 2
P/J751 Figure 22 16 DADF 2 of 2
P/J752 Figure 22 14 DADF 2 of 2
P/J753 Figure 22 13 DADF 2 of 2
P/J754 Figure 22 12 DADF 2 of 2
P/J755 Figure 22 11 DADF 2 of 2
P/J756 Figure 22 5 DADF 2 of 2
P/J757 Figure 22 4 DADF 2 of 2
P/J758 Figure 22 3 DADF 2 of 2
P/J759 Figure 22 2 DADF 2 of 2
P/J760 Figure 22 1 DADF 2 of 2
P/J761 Figure 22 17 DADF 2 of 2
P/J764 Figure 22 9 DADF 2 of 2
P/J765 Figure 22 10 DADF 2 of 2
P/J766 Figure 21 3 DADF 1 of 2
P/J767 Figure 21 18 DADF 1 of 2
P/J769 Figure 22 8 DADF 2 of 2
P/J770 Figure 22 7 DADF 2 of 2
P/J771 Figure 21 14 DADF 1 of 2
P/J772 Figure 21 15 DADF 1 of 2
P/J774 Figure 21 13 DADF 1 of 2
P/J775 Figure 21 16 DADF 1 of 2
Table 1 Plug/Jack List
Connector
Number
Figure
Number
Item
Number Figure Title
P/J776 Figure 21 17 DADF 1 of 2
P/J777 Figure 21 7 DADF 1 of 2
P/J778 Figure 21 6 DADF 1 of 2
P/J779 Figure 21 5 DADF 1 of 2
P/J780 Figure 21 12 DADF 1 of 2
P/J781 Figure 21 11 DADF 1 of 2
P/J782 Figure 21 10 DADF 1 of 2
P/J785 Figure 22 18 DADF 2 of 2
P/J786 Figure 22 6 DADF 2 of 2
P/J787 Figure 21 9 DADF 1 of 2
P/J788 Figure 21 8 DADF 1 of 2
P/J791 Figure 21 4 DADF 1 of 2
P/J820 Figure 17 4 Tray3/4 Feeder (2TM)
P/J820 Figure 19 5 Tray3/4 Feeder (TTM)
P/J821 Figure 17 7 Tray3/4 Feeder (2TM)
P/J821 Figure 19 6 Tray3/4 Feeder (TTM)
P/J822 Figure 18 5 2TM Rear Location
P/J822 Figure 20 7 TTM Rear Location
P/J824 Figure 17 5 Tray3/4 Feeder (2TM)
P/J824 Figure 19 4 Tray3/4 Feeder (TTM)
P/J825 Figure 17 6 Tray3/4 Feeder (2TM)
P/J825 Figure 20 3 TTM Rear Location
P/J826 Figure 18 6 2TM Rear Location
P/J826 Figure 20 8 TTM Rear Location
P/J841 Figure 18 4 2TM Rear Location
P/J841 Figure 20 5 TTM Rear Location
P/J842 Figure 17 10 Tray3/4 Feeder (2TM)
P/J842 Figure 20 6 TTM Rear Location
P/J2011 Figure 4 2 ROS Unit, Exit PWB
P/J2901 Figure 10 6 ESS 1 of 2
P/J7101 Figure 2 14 IIT
P/J7192 Figure 2 4 IIT
P/J7193 Figure 2 4 IIT
P/J7231 Figure 2 8 IIT
P/J7261 Figure 2 10 IIT
P/J7262 Figure 2 12 IIT
CN1 Figure 1 5 Control Panel
CN2 Figure 1 9 Control Panel
CN3 Figure 1 4 Control Panel
CN4 Figure 1 6 Control Panel
Table 1 Plug/Jack List
Connector
Number
Figure
Number
Item
Number Figure Title
