Xerox WorkCentre 5225 Service Manual

February, 2008
7-20
WorkCentre 5225, 5230
Plug/Jack Locations
Launch Version
Wiring Data
CN5 Figure 1 3 Control Panel
CN102 Figure 13 6 IOT Rear Location
CNP352 Figure 12 1 Fax Box Assembly
CNP353 Figure 12 2 Fax Box Assembly
CNP354 Figure 12 3 Fax Box Assembly
CNP356 Figure 12 4 Fax Box Assembly
CNJ352 Figure 12 1 Fax Box Assembly
CNJ356 Figure 12 4 Fax Box Assembly
CNJ359 Figure 12 5 Fax Box Assembly
CNJ360 Figure 12 6 Fax Box Assembly
CON CN3 Figure 1 11 Control Panel
CP CN1 Figure 1 7 Control Panel
F1 Figure 21 2 DADF 1 of 2
F2 Figure 21 1 DADF 1 of 2
FS812 Figure 17 11 Tray3/4 Feeder (2TM)
FS812 Figure 19 8 Tray3/4 Feeder (TTM)
FS813 Figure 17 11 Tray3/4 Feeder (2TM)
FS813 Figure 19 8 Tray3/4 Feeder (TTM)
INV CN1 Figure 1 10 Control Panel
INV CN2 Figure 1 1 Control Panel
LCD CN1 Figure 1 2 Control Panel
SJ1 Figure 5 9 Exit 2
Table 1 Plug/Jack List
Connector
Number
Figure
Number
Item
Number Figure Title
