POWER UNIT
5
4
Order Job/Part Q’ty Remarks
12 PTT motor lead (light green) 1
13 Plastic locking tie 1
14 Flushing water hose 1 (exhaust cover-to-hose joint)
15 Plastic locking tie 1
16 Hose clamp 1
17 Pilot water hose 1 (fuel cooler-to-exhaust cover)
18 Hose clamp 1
19 Pilot water hose 1 (fuel cooler-to-water outlet)
20 Oil level dipstick 1
For installation, reverse the removal
procedure.
6 × 20 mm
6 × 10 mm
6 × 10 mm
9 Nm (0.9 m • kgf, 6.5 ft • Ib)
8
7
6
4
17
5
2
3
12
11
9
10
16
18
19
19
17
15
14
13
20
1
5090
Not reusable
Not reusable
