5-33
POWR
E
OIL FILTER AND EXHAUST COVER
5
4
Order Job/Part Q’ty Remarks
8 Spring 1
9 Pressure control valve (PCV) 1 Face the longer side towards the cylinder
block.
10 Grommet 1
11 Gasket 1
12 Bolt 2
13 Anode cover 1
14 O-ring 1
15 Bolt 1
16 Anode 1
Continued on next page.
E
22
6 Nm (0.6 m • kgf, 4.3 ft • Ib)1st
12 Nm (1.2 m • kgf, 8.7 ft • Ib)2nd
18 Nm (1.8 m • kgf, 13 ft • Ib)
6 × 20 mm
6 × 30 mm
6 × 20 mm
6 × 16 mm
8 × 25 mm
LTLT
LT
572572
17
A
14 × 12 mm
23
5
4
21
20
11
10
19
18
17
7
6
12
8
9
13
16
14
15
3
1
2
A
6
2
3
7
H
C
8
4
F
D
1
5
E
G
9
0
B
5430
Not reusable
