Yamaha F115A - Page 310

6-5
E
LOWR
6
6
Order Job/Part Q’ty Remarks
9 Spacer 1
10 Washer 2
11 Wave washer 1
12 Impeller 1
13 Woodruff key 1
14 Impeller plate 1
15 Gasket 1
16 Dowel pin 2
For installation, reverse the removal
procedure.
18 Nm (1.8 m
•
kgf, 13 ft
•
Ib)
6
7
2
4
3
5
8
9
11
10
12
14
15
16
13
A
A
LTLT
LT
572572
8 × 45 mm
1
6040
Not reusable
WATER PUMP (REGULAR ROTATION MODELS)
