Yamaha F115A - Page 350

6-25
E
LOWR
2. Install:
• Needle bearing
Å For USA and Canada
ı For worldwide
Needle bearing installation
position
a
10.0 mm (0.39 in)
Needle bearing installation
position
b
184.0 mm (7.24 in)
Bearing/oil seal attachment .... 1
YB-06194 / 90890-06636
Driver rod .................................. 2
YB-06071 / 90890-06602
Bearing/oil seal depth plate .... 3
YB-06213 / 90890-06603
YB-34474
6390
Å
6400
ı
LOWER CASE ASSEMBLY
(REGULAR ROTATION MODELS)
