7-3
BRKT
E
7
Order Job/Part Q’ty Remarks
11 Clamp 1
12 Main switch leads 5
13 Trailer/PTT switch coupler 1
14 Extension, wire harness 1
15 Nut 2
16 Steering handle assembly 1
17 Nut 2
18 Bracket 1
For installation, reverse the removal
procedure.
7020
18
17
16
38 Nm (3.8 m • kgf, 27.5 ft • Ib)
38 Nm (3.8 m • kgf, 27.5 ft • Ib)
STEERING HANDLE (OPTION)
To Next Page
