Yamaha F115A - Page 528

7-25
BRKT
E
7
Order Job/Part Q’ty Remarks
9 Cam 1
10 Bolt 2
11 Clamp bracket bolt 1
12 Starboard clamp bracket 1
13 Port clamp bracket 1
14 Bushing 2
15 Grease nipple 1
16 Ground lead 1
17 Swivel bracket assembly 1
For installation, reverse the removal
procedure.
7100
CLAMP BRACKETS
