Yamaha F115A - Page 600

8-7
–+
ELEC
E
8070
3
1
2
3
4
5
6
7
8
9
99
9
A
0
4 4 57 6 890A9993
3
2
W/BW/RB/Y
P/G
P
Pu/R
Pu/B
R/Y
G/B
G
L/Y
W/B
L
Pu/G
Pu/Y
G/R
G/Y
B/Y
P/W
W/R
B
B
P/W
R/Y
R/Y
R/Y
R/Y
R/YR/Y
G/R
G/R
R/Y
P/G
Pu/R
L/YR/YR/YR/YR/Y
G/Y
R/Y
B
B
B
OB G
BBB
B
B
B
P
B
OBLR/YPu/BPu/YPu/G
B
O
O
B
Connect to:
1 Pulser coil
2 ECM
3 Ground lead
4 Intake air temperature
sensor
5 Oil pressure switch
6 Idle speed control valve
7 Throttle position sensor
8 Intake air pressure
sensor
9 Fuel injectors
0 Shift position switch
A High-pressure fuel pump
B : Black
G : Green
L : Blue
WIRE HARNESS
O : Orange
P : Pink
B/Y : Black/yellow
G/B : Green/black
G/R : Green/red
G/Y : Green/yellow
L/Y : Blue/yellow
P/G : Pink/green
P/W : Pink/white
Pu/B : Purple/black
Pu/G : Purple/green
Pu/R : Purple/red
Pu/Y : Purple/yellow
R/Y : Red/yellow
W/B : White/black
W/R : White/red
