YASKAWA E-7S SERVOPACK SGD7S

16.2 List of Parameters
16.2.2 List of Parameters
16-21
16
Parameter Lists
Pn526
4
Position Deviation Over-
flow Alarm Level at
Servo ON
1 to
1,073,741,823
1 refer-
ence
unit
5242880 All
Immedi-
ately
Setup
page
8-9
Pn528
2
Position Deviation Over-
flow Warning Level at
Servo ON
10 to 100 1% 100 All
Immedi-
ately
Setup
page
8-9
Pn529
2
Speed Limit Level at
Servo ON
0 to 10,000
1 min
-1
10000 Rotary
Immedi-
ately
Setup
page
8-9
Pn52A
2
Multiplier per Fully-
closed Rotation
0 to 100 1% 20 Rotary
Immedi-
ately
Tuning
page
10-9
Pn52B
2
Overload Warning Level 1 to 100 1% 20 All
Immedi-
ately
Setup
page
5-39
Pn52C
2
Base Current Derating
at Motor Overload
Detection
10 to 100 1% 100 All
After
restart
Setup
page
5-40
Pn530
2
Program Jog Operation-
Related Selections
0000h to
0005h
–
0000h All
Immedi-
ately
Setup
page
7-14
Pn531
4
Program Jog Operation
Travel Distance
1 to
1,073,741,824
1 refer-
ence
unit
32768 All
Immedi-
ately
Setup
page
7-14
Pn533
2
Program Jog Operation
Movement Jog Opera-
tion
1 to 10,000
Rotary:
1 min
-1
Direct
Drive:
0.1
min
-1
500 Rotary
Immedi-
ately
Setup
page
7-14
Pn534
2
Program Jog Operation
Acceleration/Decelera-
tion Time
2 to 10,000 1 ms 100 All
Immedi-
ately
Setup
page
7-14
Pn535
2
Program Jog Operation
Waiting Time
0 to 10,000 1 ms 100 All
Immedi-
ately
Setup
page
7-14
Pn536
2
Program Jog Operation
Number of Movements
0 to 1,000 Times 1 All
Immedi-
ately
Setup
page
7-14
Pn550
2
Analog Monitor 1 Offset
Voltage
-10,000 to
10,000
0.1 V 0 All
Immedi-
ately
Setup
page
9-11
Pn551
2
Analog Monitor 2 Offset
Voltage
-10,000 to
10,000
0.1 V 0 All
Immedi-
ately
Setup
page
9-11
Continued on next page.
Continued from previous page.
Parameter
No.
Size
Name
Setting
Range
Setting
Unit
Default
Setting
Applicable
Motors
When
Enabled
Classi-
fication
Refer-
ence
n.X
Program Jog Operation Pattern
0
(Waiting time in Pn535 → Forward by travel distance in Pn531) × Number of
movements in Pn536
1
(Waiting time in Pn535 → Reverse by travel distance in Pn531) × Number of
movements in Pn536
2
(Waiting time in Pn535 → Forward by travel distance in Pn531) × Number of
movements in Pn536
(Waiting time in Pn535 → Reverse by travel distance in Pn531) × Number of
movements in Pn536
3
(Waiting time in Pn535 → Reverse by travel distance in Pn531) × Number of
movements in Pn536
(Waiting time in Pn535 → Forward by travel distance in Pn531) × Number of
movements in Pn536
4
(Waiting time in Pn535 → Forward by travel distance in Pn531 → Waiting time
in Pn535 → Reverse by travel distance in Pn531) × Number of movements in
Pn536
5
(Waiting time in Pn535 → Reverse by travel distance in Pn531 → Waiting time
in Pn535 → Forward by travel distance in Pn531) × Number of movements in
Pn536
n.X Reserved parameter (Do not change.)
n.X Reserved parameter (Do not change.)
n.X Reserved parameter (Do not change.)
