YASKAWA E-7S SERVOPACK SGD7S

16.2 List of Parameters
16.2.2 List of Parameters
16-22
Pn552
2
Analog Monitor 1 Mag-
nification
-10,000 to
10,000
× 0.01 100 All
Immedi-
ately
Setup
page
9-11
Pn553
2
Analog Monitor 2 Mag-
nification
-10,000 to
10,000
× 0.01 100 All
Immedi-
ately
Setup
page
9-11
Pn55A
2
Power Consumption
Monitor Unit Time
1 to 1,440 1 min 1 All
Immedi-
ately
Setup
–
Pn560
2
Residual Vibration
Detection Width
1 to 3,000 0.1% 400 All
Immedi-
ately
Setup
page
8-54
Pn561
2
Overshoot Detection
Level
0 to 100 1% 100 All
Immedi-
ately
Setup
page
8-30,
page
8-39
Pn581
2
Zero Speed Level 1 to 10,000 1 mm/s 20 Linear
Immedi-
ately
Setup
page
1-10
Pn582
2
Reserved parameter (Do
not change.)
––
10 Linear
–––
Pn583
2
Brake Reference Out-
put Speed Level
0 to 10,000 1 mm/s 10 Linear
Immedi-
ately
Setup
page
5-31
Pn584
2
Speed Limit Level at
Servo ON
0 to 10,000 1 mm/s 10000 Linear
Immedi-
ately
Setup
page
8-9
Pn585
2
Program Jog Operation
Movement Speed
1 to 10,000 1 mm/s 50 Linear
Immedi-
ately
Setup
page
7-14
Pn586
2
Motor Running Cooling
Ratio
0 to 100
1%/
Max.
speed
0Linear
Immedi-
ately
Setup
–
Pn587
2
Reserved parameters
(Do not change.)
––
0000h Linear
–––
Pn600
2
Regenerative Resistor
Capacity
*10
Depends on
model.
*11
10 W 0 All
Immedi-
ately
Setup
page
5-53
Pn601
2
Dynamic Brake Resis-
tor Allowable Energy
Consumption
0 to 65,535 10 J 0 All
After
restart
Setup
*12
Pn603
2
Regenerative Resis-
tance
0 to 65,535 10 mΩ 0All
Immedi-
ately
Setup
page
5-53
Pn604
2
Dynamic Brake Resis-
tance
0 to 65,535 10 mΩ 0All
After
restart
Setup
*12
Pn61A
2
Overheat Protection
Selections
0000h to
0003h
–
0000h Linear
After
restart
Setup
page
6-41
Pn61B
*14
2 Overheat Alarm Level 0 to 500 0.01 V 250 All
Immedi-
ately
Setup
page
6-41
Pn61C
*14
2 Overheat Warning Level 0 to 100 1% 100 All
Immedi-
ately
Setup
page
6-41
Pn61D
*14
2
Overheat Alarm Filter
Time
0 to 65,535 1 s 0 All
Immedi-
ately
Setup
page
6-41
Continued on next page.
Continued from previous page.
Parameter
No.
Size
Name
Setting
Range
Setting
Unit
Default
Setting
Applicable
Motors
When
Enabled
Classi-
fication
Refer-
ence
n.

X Overheat Protection Selection
0 Disable overheat protection.
1
Use overheat protection in the Yaskawa Linear Servomotor.
*13
2
Monitor a negative voltage input from a sensor attached to the machine and
use overheat protection.
3
Monitor a positive voltage input from a sensor attached to the machine and
use overheat protection.
n.

X

Reserved parameter (Do not change.)
n.

X

Reserved parameter (Do not change.)
n.X

Reserved parameter (Do not change.)
