YASKAWA E-7S SERVOPACK SGD7S - Page 616

16.2 List of Parameters
16.2.2 List of Parameters
16-27
16
Parameter Lists
PnB15
2
/POUT1
0000h or
0001h
–
0000h All
After
restart
Setup
page
6-10
PnB16
2
/POUT2
0000h or
0001h
–
0000h All
After
restart
Setup
page
6-10
PnB17
2
/POUT3
0000h or
0001h
–
0000h All
After
restart
Setup
page
6-10
PnB18
2
/POUT4
0000h or
0001h
–
0000h All
After
restart
Setup
page
6-10
PnB19
2
/POUT5
0000h or
0001h
–
0000h All
After
restart
Setup
page
6-10
PnB1A
2
/POUT6
0000h or
0001h
–
0000h All
After
restart
Setup
page
6-10
PnB1B
2
/POUT7
0000h or
0001h
–
0000h All
After
restart
Setup
page
6-10
PnB1C
2
/WARN
0000h or
0001h
–
0000h All
After
restart
Setup
page
6-8
PnB1D
2
/BK
0000h or
0001h
–
0000h All
After
restart
Setup
page
5-32
Continued on next page.
Continued from previous page.
Parameter
No.
Size
Name
Setting
Range
Setting
Unit
Default
Setting
Applicable
Motors
When
Enabled
Classi-
fication
Refer-
ence
0000h The /POUT1 signal turns ON (opens) when programmable output 1 is active.
0001h The /POUT1 signal turns OFF (closes) when programmable output 1 is active.
0000h The /POUT2 signal turns ON (opens) when programmable output 2 is active.
0001h The /POUT2 signal turns OFF (closes) when programmable output 2 is active.
0000h The /POUT3 signal turns ON (opens) when programmable output 3 is active.
0001h The /POUT3 signal turns OFF (closes) when programmable output 3 is active.
0000h The /POUT4 signal turns ON (opens) when programmable output 4 is active.
0001h The /POUT4 signal turns OFF (closes) when programmable output 4 is active.
0000h The /POUT5 signal turns ON (opens) when programmable output 5 is active.
0001h The /POUT5 signal turns OFF (closes) when programmable output 5 is active.
0000h The /POUT6 signal turns ON (opens) when programmable output 6 is active.
0001h The /POUT6 signal turns OFF (closes) when programmable output 6 is active.
0000h The /POUT7 signal turns ON (opens) when programmable output 7 is active.
0001h The /POUT7 signal turns OFF (closes) when programmable output 7 is active.
0000h When an error/warning occurs (error/warning status), the /WARN signal turns ON (closes).
0001h When an error/warning occurs (error/warning status), the /WARN signal turns OFF (opens).
0000h When braking signal /BK is ON (closed), brake is released.
0001h When braking signal /BK is OFF (open), brake is released.
