YASKAWA JEPMC-MP2300-Y Series User Manual

3
Module Specifications
3.2.2
External Appearance, LED Indicators, and Switch Settings
3-8
( 3 ) Switch Settings
The DIP switch sets the operating conditions for the Basic Module when the power is turned ON.
SW1
OFFޓޓޓON
STOP
SUP
INIT
CNFG
MON
TEST
6
5
4
3
2
1
No. Name Setting Operating Mode
Default
Setting
Details
6
STOP
ON User program stopped
OFF
Stops the user program execution. Enabled only
when the power is turned ON.
OFF User program running
5
SUP
ON System use
OFF
Always leave set to OFF.
OFF Normal operation
4
INIT
ON Memory clear
OFF
Set to ON to clear the memory. If this switch is set
to OFF, the program stored in flash memory will
be executed.
OFF Normal operation
3
CNFG
ON Configuration mode
OFF
Set to ON to execute self-configuration for
connected devices.
OFF Normal operation
2
MON
ON System use
OFF
Always leave set to OFF.
OFF Normal operation
1
TEST
ON System use
OFF
Always leave set to OFF.
OFF Normal operation
