Overview of the MP2300

1.5.1

Cables

1-8

1.5 Cables and Accessories

1.5.1 Cables

The following table shows the cables that can be connected to the MP2300 Basic Module and

Optional Modules.

Module

Connector

Name

Application Model Specifications

MP2300 Basic

Module and

SVB-01

CPU I/O External I/O

JEPMC-W2060-



Used between

CPU I/O and External I/O

M-I/II

MECHATROLINK-I

，

MECHATROLINK-

cable

JEPMC-W6002-



*with MECHATROLINK

connectors on both ends

Used between the devices listed below

SVB-01 and I/O Unit,

SVB-01 and SGDH-



E+NS100

SVB-01 and SGDH-



E+NS115

SVB-01 and SGDS-





JEPMC-W6003-



*with MECHATROLINK

connectors on both ends

*with ferrite core

JEPMC-W6011-



*with a MECHATROLINK

connector and loose wires

Used between the devices listed below

SVB-01 and SGD-



SVB-01 and SGDB-



JEPMC-W6022 Terminator

SVA-01

CN/1

CN/2

Cable for analog reference

input SERVOPACK

JEPMC-W2040-



Used between the devices listed below

SVA-01 and

SGDM/SGDH

SVA-01 and SGDS-





SVA-01 and SGDS-





LIO-01

LIO-02

I/O

External I/O

JEPMC-W2061-



*Loose wires on one end

Used between

LIO-01/02 and External I/O device

LIO-04

LIO-05

CN/1, CN/2

External I/O

JEPMC-W6060-



*Loose wires on one end

Used between

LIO-04/05 and External I/O device

DO-01 CN/1, CN/2

External outputs

JEPMC-W6060-



*Loose wires on one end

Used between

DO-01 and External I/O device

AI-01 CN/1, CN/2

Analog external outputs

JEPMC-W6080-



*Loose wires on one end

Used between

AI-01 and Analog external output device

Communication

Module

PORT

(Common to all

communication

modules)

RS-232C communication

cable

JEPMC-W5310-



Used between

RS-232C port and 25-pin male D-sub

connector

JEPMC-W5311-



Used between

RS-232C port and DOS/V

218IF-01 10Base-T

Ethernet communication

cable

Use a commercially

available cable.

Cross cable (Category 3 min.)

217IF-01 RS422/485

RS422/485 communication

cable

Module-side connector:

1010214-52A2JL (manufactured by

Sumitomo 3M)

Cable-side connector:

10114-3000VE (manufactured by

Sumitomo 3M)

Shell: 10314-52A0-008 (manufactured

by Sumitomo 3M)

260IF-01 DeviceNet

DeviceNet communication

cable

Module-side connector:

MSTB2-5/5-GF-5.08AM

(manufactured by Phoenix Contact K.K.)

261IF-01 PROFIBUS

PROFIBUS communication

cable

Module-side connector:

17LE-13090-27(D33C) (manufactured

by DDK Ltd.)
