Overview of the MP2300
1.2.2
MP2300 Modules
1-4
1.2.2 MP2300 Modules
The following table shows the names and descriptions of the Basic Module and Optional Modules.
1.2.3 MP2300 Series Models
The following table shows the possible combinations of the MP2300 Basic Module with the PS, the
CPU, and the MB, and Optional Modules.
Group Name Description Model Remarks
Basic Module
Basic Module MP2300 JAPMC-MP2300
MECHATR
O
LINK-I,
MECHATR
O
LINK-II
8 input, 4 outputs
Optional
Modules
Motion
Modules
MECHATROLINK-II
Motion-control Module
SVB-01 JAPMC-MC2310 MECHATROLINK-I, -II, 16 axes maximum
Analog Output Motion-
control Module
SVA-01 JAPMC-MC2300 Analog output, 2 axes maximum
I/O Modules
I/O Module LIO-01 JAPMC-IO2300
16 inputs, 16 outputs (sink mode output)
1 pulse input
I/O Module LIO-02 JAPMC-IO2301
16 inputs, 16 outputs (source mode output)
1 pulse input
I/O Module LIO-04 JAPMC-IO2303 32 inputs, 32 outputs (sink mode output)
I/O Module LIO-05 JAPMC-IO2304 32 inputs, 32 outputs (source mode output)
Analog Input Module AI-01 JAPMC-AN2300 Analog input
Output Module DO-01 JAPMC-DO2300 64 outputs (sink mode output)
Communica-
tion
Modules
E
thernet
Communication
Module
218IF-01 JAPMC-CM2300 RS-232C and Ethernet communication
General-purpose Serial
Communication
Module
217IF-01 JAPMC-CM2310 RS-232C and RS422/485 communication
DeviceNet
Communication
Module
260IF-01 JAPMC-CM2320 RS-232C and DeviceNet communication
PROFIBUS
Communication
Module
261IF-01 JAPMC-CM2330 RS-232C and PROFIBUS communication
No. Model Combination of Modules
1
JEPMC-MP2300
2
JEPMC-MP2300-Y1
3
JEPMC-MP2300-Y2
Basic
Module
Basic
Module
217
IF
218
IF
LIO
01
Basic
Module
218
IF
LIO
01
LIO
01
