YASKAWA JEPMC-MP2300-Y Series User Manual

3.6
Dimensional Drawings
3-65
3.6.2 Optional Modules
The Optional Modules have the following dimensions. Height: 125 mm; Depth: 95 mm
The following figures show the dimensions of the connector.
SVA-01 SVB-01
Unit: mm
(5)
(41)
LIO-01 / LIO-02 LIO-04 / LIO-05 / DO-01
(2)
(48) (41)
(41)
(15) (5)
