YASKAWA JEPMC-MP2300-Y Series User Manual

7
Motion Commands
7.2.16
Read SERVOPACK Parameter (PRM_RD)
7-68
7.2.16 Read SERVOPACK Parameter (PRM_RD)
The PRM_RD command reads the setting of the SERVOPACK parameter with the specified parame-
ter number and parameter size. It stores the parameter number in Servo Constant Number (monitor-
ing parameter IW

36) and the setting in Servo User Constant (monitoring parameter IL

38).
( 1 ) Executing/Operating Procedure
1.
Check to see if all the following conditions are satisfied.
2.
Set OW

08 to 17 to execute the PRM_RD motion command.
The PRM_RD command will store the specified parameter number in the Servo Constant
Number (monitoring parameter IW

36) and the parameter setting in Servo User Constant
(monitoring parameter IL

38).
IW

08 will be 17 during command execution.
IB

090 will turn ON during the command processing and will turn OFF when the command
processing has been completed.
3.
Set OW

08 to 0 to execute the NOP motion command and then complete the
reading operation.
( 2 ) Holding and Aborting
The Command Pause bit (OB

090) and the Command Abort bit (OB

091) cannot be used.
( 3 ) Related Parameters
[ a ] Setting Parameters
No. Execution Conditions Confirmation Method
1 There are no alarms.
Both IL

02 and IL

04 are 0.
2 Motion command execution has been completed.
IW

08 is 0 and IB

090 is OFF.
Parameter Name Setting
OW

08
Motion Command
The SERVOPACK parameter is read when this parameter is set to 17.
OB

090
Command Pause
This parameter is ignored for PRM_RD command.
OB

091
Command Abort
This parameter is ignored for PRM_RD command.
OW

50
Servo Constant Number
Set the number of the SERVOPACK parameter to be read.
OW

51
Servo Constant Number
Size
Set the size of the SERVOPACK parameter to be read.
Set the size as the number of words.
Example: For 4 bytes, set "2."
