Motion Commands
7.2.4
Interpolation (INTERPOLATE)
7-36
z
Setting Parameters
7.2.4 Interpolation (INTERPOLATE)
The INTERPOLATE command positions the axis according to the target position that changes in
sync with the high-speed scan. The positioning data is generated by a ladder program.
Speed feed forward compensation can be applied.
Torque feed forward gain can be used when interpolation commands (INTERPOLATE) are sent
using SGDS SERVOPACKs.
Torque feed forward gain is set in Torque/Thrust Reference (setting parameter OL

0C). The
required conditions are as follows:
SERVOPACK parameter Pn002.0 = 2
SGDS communication interface version 8 or later
( 1 ) Executing/Operating Procedure
1.
Check to see if all the following conditions are satisfied.
2.
Set the following motion setting parameters.
Target Position: OL

1C
Acceleration/Deceleration Filter Type: OW

03
Speed Loop P/PI Switch: OW

01
Speed Feed Forward Compensation: OW

30
3.
Set OW

08 to 4 to execute the INTERPOLATE motion command.
Positioning will start. The travel speed is calculated automatically.
IW

08 will be 4 during the positioning.
The Target Position (OL

1C) will be updated every high-speed scan.
IB

0C1 will turn ON when the axis reaches the target position and the positioning has been
completed.
4.
Set OW

08 to 0 to execute the NOP motion command and then complete the
Parameter Name Setting
OW

3C
Home Return Type 19: INPUT Only Method
OL

10
Speed Reference
Set the positioning speed to use after detecting the INPUT signal. The sign
is ignored. The travel direction will depend on the sign of the Home Offset.
OL

40
Creep Speed
Set the speed and the travel direction (sign) to use when starting a zero point
return.
OL

42
Home Offset
Set the distance to travel from the point the INPUT signal is detected.
The travel direction will depend on the sign.
OB

05B
INPUT Signal for Zero
Point Return
This signal must be turned ON from the ladder program.
R
No. Execution Conditions Confirmation Method
1 There are no alarms.
Both IL

02 and IL

04 are 0.
2 The Servo ON condition.
IB

001 is ON.
3 Motion command execution has been completed.
IW

08 is 0 and IB

090 is OFF.
