MP2300 Basic Module Definition Data
5-34
5.5 Definition Data Refreshed by Self-configuration and Allocation
Examples
The definition data refreshed when self-configuration is executed and module configuration defini-
tion examples according to combination of modules are shown below.
5.5.1 MP2300 Basic Module Definition Data
( 1 ) I/O Allocations
( 2 ) MECHATROLINK Transmission Definition Data
The following table shows the MECHATROLINK transmission definitions that are automatically set
based on the detected communication method and number of slaves.
The communication cycle and number of retry stations in MECHATROLINK-II 32-byte Mode
change according to the highest station number of the detected slaves as shown in the following
table.
Item Allocation
Digital input (DI 18 points) IW0000
Digital output (DO 4 points) OW0001
MECHATROLINK
Leading I/O registers: IW0010/OW0010
Ending I/O registers: IW040F/OW040F
(Input registers: IW0010 to IW040F
Output registers: OW0010 to OW040F)
Communication type
MECHATROLINK-II
(32-byte)
MECHATROLINK-II
(17-byte)
MECHATROLINK-
Ⅰ
Transmission speed 10 Mbps 10 Mbps 4 Mbps
Transmission bytes
(transfer bytes)
32 17 17
Communication cycle
1 ms
*
2 ms
*
1 ms 2 ms
Maximum number of
slave stations
* *1415 14
Number of retry stations * * 1 0
-
SigmaWin Not supported Not supported
-
Highest Slave Station
Number
Communication
Cycle (ms)
Number of Retry Station
1 to 8 1 1
91 0
10 to 16 2 5
17 to 21 2
Determined by the following
equation.
21 - (Highest station number)
