1.4
Devices Connectable to MECHATROLINK
1-7
1.4 Devices Connectable to MECHATROLINK
The devices that are compatible with MECHATROLINK and can be connected to the
MP2300 and the SVB-01 Module are listed below.
1.4.1 SERVOPACKs
1.4.2 Modules
Model Number Details MECHATROLINK-I MECHATROLINK-II
SGDS-

1

SGDS SERVOPACK
Yes Yes
SGDH-

E
JUSP-NS115
SGDH SERVOPACK
NS115 MECHATROLINK-II Interface Unit
Yes Yes
SGDH-

E
JUSP-NS100
SGDH SERVOPACK
NS110 MECHATROLINK-I Interface Units
Yes No
SGD-
N
SGDB-

AN
MECHATROLINK compatible AC SERVO-
PACKs
Yes No
Model Number Details MECHATROLINK-I MECHATROLINK-II
JEPMC-IO2310
64-point I/O Module
24 VDC, 64 inputs, 64 outputs (sink mode
output)
Yes Yes
JEPMC-IO2330
64-point I/O Module
24 VDC, 64 inputs, 64 outputs (source
mode output)
Yes Yes
JEPMC-PL2900
Counter Module
Reversible counter, 2 channels
Yes Yes
JEPMC-PL2910
Pulse Output Module
Pulse output, 2 channels
Yes Yes
JEPMC-AN2900
A/D Module
Analog inputs,
−
10 to 10 V, 4 channels
Yes Yes
JEPMC-AN2910
D/A Module
Analog outputs,
−
10 to 10 V, 2 channels
Yes Yes
JEPMC-IO350
64-point I/O Module
24 VDC, 64 inputs, 64 outputs
Yes No
JAMSC-120DDI34330
DC Input Module
12/24 VDC, 16 inputs
Yes No
JAMSC-120DDO34340
DC Output Module
12/24 VDC, 16 outputs
Yes No
JAMSC-120DAI53330
AC Input Module
100 VAC, 8 inputs
Yes No
JAMSC-120DAI73330
AC Input Module
200 VAC, 8 inputs
Yes No
JAMSC-120DAO83330
AC Output Module
100/200 VAC, 8 outputs
Yes No
JAMSC-120DRA83030
Relay Module
Wide voltage range relay contacts,
8 contact outputs
Yes No
JAMSC-120AVI02030
A/D Module
Analog inputs,
−
10 to 10 V, 4 channels
Yes No
JAMSC-120AVO01030
D/A Module
Analog outputs,
−
10 to 10 V, 2 channels
Yes No
JAMSC-120EHC21140
Counter Module
Reversible counter, 2 channels
Yes No
JAMSC-120MMB20230
Pulse Output Module
Pulse output, 2 channels
Yes No
JEPMC-REP2000 MECHATROLINK-II Repeater
No Yes
JEVSA-YV250 MYVIS (image processing device)
Yes Yes
To Next Page
