3.3
Motion Modules (Optional)
3-19
îš„
Transmission Distance and Maximum No. of Slave Stations
* The values in parentheses apply when a JEPMC-REP2000 Repeater is used.
A JEPMC-REP2000 Repeater must be used if 17 or more slave stations are connected when
using MECHATROLINK-II communication.
3.3.2 SVA-01 Module
( 1 ) Overview and Features
The SVA-01 Module is a motion control module with analog outputs. Each Module can control
Servos or Inverters for up to 2 axes.
The Module has two connectors (CN1 and CN2) for connecting SERVOPACKs and external I/
O. Each connector provides analog outputs for speed references and torque references, analog
inputs for feedback speed monitoring and torque monitoring, pulse input phases A, B, and C (5-
V differential), and general-purpose digital I/O.
The control cycle is fixed at 500 µs, enabling high-precision control without being affected by
the high-speed scan cycle.
＜
Features
＞
• Two analog outputs for Servos for 2 axes
• Position control, speed reference outputs, torque reference outputs, or phase control can be
performed independently for each axis.
Communication Method
Transmission Distance
(Total Network Length)
Maximum No. of
Slave Stations
MECHATROLINK-
I
50 m
(Can be extended up to 100 m by connecting repeaters.)
14
MECHATROLINK-
II
30 m
(Can be extended up to 100 m by connecting repeaters.)
16 (21)
*
50 m
(Can be extended up to 100 m by connecting repeaters.)
15 (21)
*
Servo Controls
• Speed references
• Position control
• Torque references
• Phase control
• Zero point returns
Monitor Functions
Same as above
System bus interface
SERVOPACK parameters
OW
I W
System bus connector
Servo connector
CN2
CN1
2 analog outputs: Speed reference
Torque reference
Pulse inputs:
Phase A/B/C (5-V differential)
6 general-purpose digital inputs (of which 2 are latch inputs)
6 general-purpose digital outputs
2 analog inputs: Speed monitor
Sensor ON output, 5 V/24 V
CN3
Torque (thrust) reference
monitor
Same
as
above
To Next Page
