218IF-01 Module
3-52
[ b ] Switch Settings
The following table shows the 218IF-01 Module switch settings.
[ c ] Offline Self-diagnostic Test
Turn the TEST switch ON and the INIT switch OFF, and then turn ON the power supply to execute
the Offline Self-diagnostic Test. The following table shows the status of the LED indicators when the
218IF-01 Module detects a malfunction.
* Indicates the number of blinking.
( 3 ) Specifications
The specifications of 218IF-01 Module are as follows.
[ a ] Hardware Specifications.
Switch Name Setting Function
Factory
Setting
INIT
Initial Startup
ON
For engineering communications. Starts the
Module using the default parameters except setting
of automatic reception functions. Given higher
priority than the Basic Module Flash Startup and
Self-configuration Startup.
OFF
OFF
Set to OFF for Basic Module Flash Startup and
Self-configuration Startup.
TEST
TEST
ON
System use
OFF
OFF
Normal operation (Always leave set to OFF.)
INIT
TEST
ON
OFF
Item Details
LED Indicators
RUN ERR TX RX
Flash Checksum
Error
A flash memory checksum error has been
detected.
Not lit
Blinking
(twice)
∗
Not lit Not litSRAM Error
A SRAM hardware error has been detected.
Blinking
(3 times)
∗
CPU Interface Error
A CPU data transmission error has been
detected.
Blinking
(5 times)
∗
Communication
Error
A communication error has been detected.
Blinking
(4 times)
∗
Depends on status.
Watchdog Error
A watchdog timeout error has been detected.
Blinking
(15 times)
∗
Depends on status.
Item Specifications
Classification
Communication Module
Name
218IF-01
Model
JAPMC-CM2300
Communication Ports
RS-232C 1 port
（
PORT
）
Ethernet 1 port
（
10Base-T
）
Indicators
Module status LED indicators
RUN (green)
ERR (red)
STRX (green)
COL (red)
TX (green)
RX (green)
