YASKAWA JEPMC-MP2300-Y Series

4
Mounting and Wiring
4.2.3
MECHATROLINK Connectors
4-12
( 3 ) Cable Connections between the MP2300 and I/O Units and the MP2300 and SERVOPACKs
Use the MECHATROLINK cable JEPMC-W6002-

or JEPMC-W6003-

for connection
between the MP2300 and I/O units or SERVOPACKs
*1
.
The connection diagram using MECHATROLINK cable JEPMC-W6002-

or JEPMC-W6003-

*2
is shown below.

Use MECHATROLINK cable JEPMC-W6011-
 when connecting SERVOPACK SGD-
N or SGDB-AN. (Refer to ( 4 )
Cable Connections between the MP2300 and SGD-
 N and
SGDB-

AN SERVOPACKs
).

The JEPMC-W6003-
 cable has a ferrite core.
1
2
3
4
1
2
3
4
Shell Shell
Pin number
Signal Name
(NC)
/DATA
DATA
SH
Shield Shield
Signal Name
(NC)
/DATA
DATA
SH
JEPMC-W6002-
JEPMC-W6003-
MP2300/SVB01
I/O Unit or SERVOPACK
