YASKAWA JEPMC-MP2300-Y Series User Manual

4
Mounting and Wiring
4.4.2
LIO-04/LIO-05 Module Connections
4-42
( 8 ) LIO-04 Module Connector Connection Examples
■
CN1 Connector Connection Example

Check the polarity of the external power supply when wiring. An adverse connection may cause a
load malfunction.

The pins No. 39 and 43 and the pins No. 46 and 50 are internally connected. Connect them exter-
nally as well.
JEPMC-IO2303
+5V
+-
+-
24 VDC
Input 0
Input 1
Input 6
Input 7
+-
+-
24 VDC
6
7
32
10
35
1
2
27
5
30
CN1 connector
pin No.
Com-
mon 1
Com-
mon 2
Input 8
Input 9
Input 14
Input 15
Internal circuit
5.6 kΩ
Photocoupler
R
R
Photocoupler
Fuse blowout
detection circuit
38
12
13
41
17
42
16
L
L
L
L
L
24 VDC
+-
43
37
L
Output 1
39
15
Output 2
Output 3
Output 5
Output 6
Output 7
Output 8
Output 4
R
L
L
Photocoupler
45
19
20
48
24
49
23
L
L
L
L
L
24 VDC
+-
50
44
L
Output 9
46
22
Output 10
Output 11
Output 13
Output 14
Output 15
Output 16
Output 12
R
L
L
Fuse blowout
detection circuit
