YASKAWA JEPMC-MP2300-Y Series User Manual

4
Mounting and Wiring
4.4.2
LIO-04/LIO-05 Module Connections
4-44
( 9 ) LIO-05 Module Connector Connection Examples
■
CN1 Connector Connection Example

Check the polarity of the external power supply when wiring. An adverse connection may cause a
load malfunction.

The pins No. 15 and 40 and the pins No. 22 and 47 are internally connected. Connect them exter-
nally as well.
+
-
-
+
24 VDC
Com-
mon 1
Com-
mon 2
1
CN1 connector
pin No.
Input 0
Input 1
2
27
Input 6
Input 7
5
30
6
7
32
Input 8
Input 9
10
35
Input 14
Input 15
JEPMC-IO2304
+
-
-
+
DC24V
+5V
5.6 kΩ
Photocoupler
Internal
circuit
R
R
L
L
L
L
L
L
15
12
Output 0
37
Output 1
13
Output 2
38
40
24 VDC
+
-
41
17
42
16
39
Output 4
Output 5
Output 6
Output 7
Photocoupler
L
Output 3
R
R
L
L
L
L
L
L
L
22
19
Output 8
44
Output 9
20
Output 10
45
47
24 VDC
+
-
48
24
49
23
46
Output 12
Output 13
Output 14
Output 15
Photocoupler
L
Output 11
R
R
L
Fuse blowout
detection circuit
Fuse blowout
detection circuit
