YASKAWA JEPMC-MP2300-Y Series User Manual

4
Mounting and Wiring
4.4.4
AI-01 Module Connections
4-56
( 5 ) Circuit Configuration
DC/DC
Converter
+5V
0V
+15V
-15V
0V
D/A
Converter
Internal circuit
+5V
Photocoupler
Voltage input
Current input
Mode
10
12
25
23
-
+
GND
CH8
11
Multiplexer
Ground
Voltage input
Current input
Mode
4
6
19
17
-
+
GND
CH2
5
Voltage input
Current input
Mode
Ground
1
3
16
14
2
-
+
GND
CH1
Ground
Shell
R R
R
RR R
RR R
10k
10k
256.5
10k
10k
256.5
10k
10k
256.5
