4
Mounting and Wiring
4.5.3
260IF-01 Module
4-70
îš„
T-branch, Multi-branch, and Drop-line connections
[ c ] Slave Mode
The following diagram shows the system configuration for slave mode.
FG
Power supply for communication
External power supply for I/O
Internal power supply for I/O
PS
121 Ω
Terminator
PS
PS
121 Ω
Terminator
I/O I/O I/O I/O I/O
MP2300
260IF-01
Power-supply tap for communications
(With reverse current protection
for when several power supplies are
connected.)
MP2300
YASKAWA
Þ“
Þ“
Þ“
Option
Option
260IF-01
Trunk line cable
Drop line cable
External power supply line for I/O
Internal power supply line for I/O
Power supply line for communication
PS
FG
Trunk line cable
Drop line cable
External power supply line for I/O
121 Ω
Terminator
Internal power supply line for I/O
Power supply line for communication
121 Ω
Terminator
Power-supply tap for communications
(With reverse current protection for
when several power supplies are connected.)
Power supply for communication
External power
supply line for I/O
Internal power supply line for I/O
PS
PS
I/O I/O
MP2300
260IF-01
Slave mode
MP2300
260IF-01
MP2300
YASKAWA
Þ“
Þ“
Option
Option
260IF-01
To Next Page
