YASKAWA JEPMC-MP2300-Y Series User Manual

12
Maintenance and Inspection
12.4.4
System Register Configuration and Error Status
12-20
[ b ] LIO-01/LIO-02 Module Error Status
■
Example: Slot 1
[ c ] 260IF-01 Module Error Status
■
Example: Slot 3
( 7 ) Module Information
(Bit No.) F --------------------------------------------- 8 7 --------------------------------------------- 0
SW00224 Error Code (I/O error = 2) Sub-slot No. (= 1)
SW00225 Error Code (I/O error = 2) Sub-slot No. (= 2)
SW00226 Not used
…………………………………………
Not used
SW00227 Not used
…………………………………………
Not used
SW00228 Not used
…………………………………………
Not used
SW00229 Not used
…………………………………………
Not used
SW00230 Not used
…………………………………………
Not used
SW00231 Not used
…………………………………………
Not used
(Bit No.) F --------------------------------------------- 8 7 --------------------------------------------- 0
SW00240
Error Code
(Station error = 1)
Sub-slot No. (= 2)
SW00241 ST15
…………………………………………
ST0
SW00242 ST31
…………………………………………
For ST16
SW00243 ST47
…………………………………………
ST22
SW00244 ST63
…………………………………………
ST48
Name Register No. Remarks
Module
Information
SW00800 Basic Module (C380H)
SW00801 Reserved by the system.
SW00802 CPU Software version (BCD)
SW00803 Number of sub-slots (0004H)
SW00804 CPU Function ID (C310H)
SW00805 CPU Function Module Status
SW00806 I/O Function Module ID (8070H)
SW00807 I/O Function Module Status
SW00808 SVB Function Module ID (9113H)
SW00809 SVB Function Module Status
SW00810 SVR Function Module ID (9210H)
SW00811 SVR Function Module Status
SW00812 to SW00815 Reserved by the system.
SW00816 to SW00823 Slot 1
SW00824 to SW00831 Slot 2
SW00832 to SW00839 Slot 3
…
SW01008 to SW01015 Reserved by the system (Slot 26)
