Zebra VC8300 User Manual

Data Capture
100
2. Ensure that the two devices are within 10 meters (32.8 feet) of one another.
3. On the VC8300, swipe up from the bottom of the Home screen and touch .
Figure 74 Bluetooth Pairing Utility
4. Using the RS507/RS507x/RS6000, scan the barcode on the screen or scan the barcode on the right side of
the VC8300.
The RS507/RS507x/RS6000 emits a high/low/high/low beeps. The Scan LED flashes green indicating that
the scanner is attempting to establish connection with the VC8300. When connection is established, the
Scan LED turns off and the scanner emits one string of low/high beeps.
5. On the VC8300, touch .
Pairing Using Human Interface Device
To pair the RS507/RS507x/RS6000 with the VC8300 using HID:
1. Place the RS507/RS507x/RS6000 in Human Interface Device (HID) mode. If the scanner is already in HID
mode, skip to step 2.
a. Remove the battery from the RS507/RS507x/RS6000.
b. Press and hold the Restore key.
c. Install the battery onto the RS507/RS507x/RS6000.
d. Keep holding the Restore key for about five seconds until a chirp is heard and the Scan LEDs flash
green.
e. Scan the barcode below to place the RS507/RS507x/RS6000 in HID mode.
Figure 75 RS507/RS507x Bluetooth HID Barcode

Zebra VC8300 Specifications

General

Display diagonal	8 \
Touchscreen type	Capacitive
Display resolution	1280 x 720 pixels
Flash memory	32 GB
Internal memory	4 GB
Internal memory type	-
Number of cores	8
Processor model	660
Processor family	Snapdragon
Processor frequency	2.2 GHz
Operating system version	8.1
Operating system installed	Android
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth version	5.0
Speakers	Mono
RS-232 input ports	2
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	1
Operating temperature (T-T)	-30 - 50 °C
Battery capacity	- mAh
Product color	Black
Keyboard layout	QWERTY
International Protection (IP) code	IP66
Harmonized System (HS) code	84713000

Weight and Dimensions

Depth	90 mm
Width	276 mm
Height	238 mm
Weight	3700 g
