Application Deployment
209
13.On the host computer, open a command prompt window and use the adb command:
adbdevices.
The following displays:
Listofdevicesattached
XXXXXXXXXXXXXXXdevice
(where XXXXXXXXXXXXXXX is the device number).
NOTE: If device number does not appear, ensure that ADB drivers are installed properly.
14.Type:
adbrebootrecovery
15.Press Enter. The System Recovery screen appears.
16.Press the Up and Down buttons to navigate to apply from adb.
17.Press the Power button.
18.On the host computer command prompt window type:
adbsideload<file>
where: <file> = the path and filename of the zip file.
19.Press Enter. The Factory Reset package installs and then the Recovery screen appears.
20.Press the Power button to reboot the device.Replace the top cover.
21.Secure the top cover to the device using the four screws. See Figure 135 on page 203.
22.Torque the screws to 6kg-cm (5.2lbs-in).
Storage
The device contains four types of file storage:
Random Access Memory (RAM)
Internal storage
External storage (USB drive)
Enterprise folder.
Random Access Memory
Executing programs use RAM to store data. Data stored in RAM is lost upon a reset. The operating system
manages how applications use RAM. It only allows applications and component processes and services to use
RAM when required. It may cache recently used processes in RAM, so they restart more quickly when opened
again, but it will erase the cache if it needs the RAM for new activities.
1. To view the amount of free and used memory, swipe down from the Status bar to open the Quick Access
panel and then touch .

Table of Contents

Other manuals for Zebra VC8300

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Zebra VC8300 and is the answer not in the manual?

Zebra VC8300 Specifications

General IconGeneral
Display diagonal8 \
Touchscreen typeCapacitive
Display resolution1280 x 720 pixels
Flash memory32 GB
Internal memory4 GB
Internal memory type-
Number of cores8
Processor model660
Processor familySnapdragon
Processor frequency2.2 GHz
Operating system version8.1
Operating system installedAndroid
Wi-Fi standards802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth version5.0
SpeakersMono
RS-232 input ports2
Headphone connectivity3.5 mm
USB 2.0 ports quantity1
Operating temperature (T-T)-30 - 50 °C
Battery capacity- mAh
Product colorBlack
Keyboard layoutQWERTY
International Protection (IP) codeIP66
Harmonized System (HS) code84713000
Weight and Dimensions IconWeight and Dimensions
Depth90 mm
Width276 mm
Height238 mm
Weight3700 g
