Zebra VC8300 User Manual

219
Specifications
Introduction
The following tables summarize the device’s intended operating environment and technical
specifications.
Technical Specifications
Table 18 Technical Specifications
Item Description
Physical and Environmental Characteristics
Dimensions 276 mm L x 238 mm W x 90 mm D
10.9 in. L x 9.4 in. W x 3.5 in. D
Weight 3.7 kg (8.2 lbs)
Display:
Size:
Resolution:
Brightness:
8 in. color WXGA
1280 x 720 LCD with LED backlight; 24 bit color depth
1000 NITs
UPS Battery Rechargeable UPS battery for operation during power loss
IP Sealing IP 66
Interface Ports Standard sealed and secured connectors:
• Two RS-232 serial port
• One standard USB port
• One powered USB port
• One 3.5 mm audio jack
Thermal Shock -30°C to 50°C (-22°F to 122°F)
User Environment
Operating Temperature -30°C to 50°C (-22°F to 122°F)
Storage Temperature -40°C to 60°C (-40°F to 140°F)
Relative Humidity 5% to 95% non-condensing (standard version)
5% to 95% condensing (freezer version with internal heating)

Zebra VC8300 Specifications

General

Display diagonal	8 \
Touchscreen type	Capacitive
Display resolution	1280 x 720 pixels
Flash memory	32 GB
Internal memory	4 GB
Internal memory type	-
Number of cores	8
Processor model	660
Processor family	Snapdragon
Processor frequency	2.2 GHz
Operating system version	8.1
Operating system installed	Android
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth version	5.0
Speakers	Mono
RS-232 input ports	2
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	1
Operating temperature (T-T)	-30 - 50 °C
Battery capacity	- mAh
Product color	Black
Keyboard layout	QWERTY
International Protection (IP) code	IP66
Harmonized System (HS) code	84713000

Weight and Dimensions

Depth	90 mm
Width	276 mm
Height	238 mm
Weight	3700 g
